Automatic Beam Saw BS300 (Heavy Duty)
Product Categories
Sliding Panel Saw
Manual Edge Band
Automatic Edge Band
Multi Head Boring
NC Boring Center
Cold & Hot Press
Brochures
Download our brochure to explore our products, services, and business solutions.
Get A quote
Product Specification
| Model | BS 330 (HEAVY DUTY) |
|---|---|
| Max. Panel (L X W) | 3200 X 3200 mm |
| Sawing Thickness | 90/120 mm |
| Main Saw Dia. | 350-400 mm |
| Main Saw Shaft Dia. | 75 mm |
| Main Saw Speed | 4800 m/min. |
| Scoring Saw Dia. | 200 mm |
| Scoring Saw Shaft Dia. | 50 mm |
| Scoring Saw Speed | 7000 rpm |
| Saw Carriage Cutting Speed | 0-100 m/min. |
| Saw Carriage Backward Speed | 0-120 m/min. |
| Main Saw Drive Motor | 15 KW |
| Scoring Saw Drive Motor | 2.2 KW |
| Saw Carriage Servo Motor | 2 KW |
| Feeding Servo Motor | 2 KW |
| High Voltage Air Supply Motor | 2.2 KW x 2 |
| Automatic Feed Speed | 0-120 m/min. |
| Air Pressure | 6-8 Mpa |
| Side Alignment System | Yes |
| Optimized Software with Label Printer | Yes |
| Dimension | 5552 x 6400 x 2000 mm |
| Quantity of Mechanical Hand | 9 Pcs |
| Air Floating Table | 3 Pcs |
| Diameter of Dust Collecting Holes | 200 x 2 pcs / 100 x 2 pcs |
| Weight | 5500 kg |
| Voltage | 415 V / 50Hz |
| Total Power | 25.5 kw |
